#930 G Scale Straight Centerset Shank Couplers with Body Mount Gearboxes - Rust
$14.39
Availability:
In stock
10 in stock
SKU
930
#930 G Scale Straight Centerset Shank Couplers with Body Mount Gearboxes - Rust is available to buy in increments of 1
#930 Straight Centerset Shank Couplers with Body Mount Gearboxes - Rust - G Scale
 |
 |
This industry leading coupler features Original Style Head Straight Centerset Shank Couplers, and #878 G Scale centering spring and comes complete with #910R Body Mount Gearboxes and lids.
It is not recommended to use a metal coupler directly on a metal surface or in a metal draft gearbox to avoid possible electrical crossover and shorting that may cause damage.
One pair per package
UPC: 765484009306
Made in the U.S.A.
G-Scale
- Simple Drop in Design
- Trouble Free Operation
- Compatible with All Kadee® G-Scale Couplers
- World-Renowned Quality & Performance
- They just Last & Last & Last...
Package Includes:
- (2) Each #930 Original Style Plastic Couplers - Straight Centerset Shank
- (2) Each #910R Body Mount Gearbox & lids
- (3) Each #878 Centering Springs
- (1) Each #860 Knuckle Springs
- (4) Each #4 x 3/4" Screws
- (4) Each #4 x 1" Screws
#930 Plastic Coupler Features:
| Material | - Plastic |
| Shank Length | - (13/16") (Back of the Coupler Head to center hole of Draft Gearbox) |
| Coupler Offset | - Centerset |
| Centering Spring | - #878 G Scale Centering Springs |
| Knuckle Spring | - #860 G Scale Knuckle Springs |
| Head | - Original Style Head |
| Works In Place of | - #830, #906, & #906R G Scale Straight Centerset Couplers |
| Works With | - #910, #910R Draft Gearboxes |
#910R Plastic Draft Gearboxes & Lids Features:
| Material | - Plastic |
| Dimensions | - 1 21/32"L x 15/32"W x 13/32"H |
| Works With | - #830, #906, #906R, & #930 Couplers |
Mounting Specifications:
| Mounting Height | - 1 19/64" |
| Centerline | - 1 1/8" |
| Trip Pin Height | - 1/8" |
| Mounting Holes | - #4 Screws are the most commonly used. (Screw length will vary) |
Recommended Tools:
- #880 G Scale Coupler Height Gauge
- #231 Greas-em Dry Graphite Lubricant
- #237 Coupler Trip Pin Pliers
- #240 Double Headed Pin Vise
- #241 Dual Tool Manual Uncoupling Tool and Spring Pick
Distributor must purchase in bundles of 6
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov WARNING: CHOKING HAZARD - Small Parts - Not for children under 14 years.Kadee Quality Products Co. products are not toys and are not intended for children under 14 years old.
